Tinkercad does however let you import vector designs which can then be transformed into 3D models. Unlike graphic design programs, these 3D modeling apps don't really allow for smooth curves and multi-layer sketching. Unlike raster images (images constructed of dots and pixels like photographs), vector image files contain lines, points, and curves that CAD programs can interpret and manipulate.ĭrawing custom designs in Tinkercad, or Onshape even, can be really challenging. Vector images are 2D images in a CAD-based format. I also made a CAD Instructable a few years back that mentions many different programs for various applications. If you're looking for more guidance with these programs, I have an extensive collection of Tinkercad tutorials and Onshape tutorials on my digital classroom channel that are all designed to be to the point, easy to follow, and student friendly. Sometimes I'll use Onshape to design a more detailed base with a chamfer, taper, or fillet feature, then import that model into Tinkercad to incorporate it with the rest of the design. I like to use Tinkercad to combine existing models too like in the rock, paper, and scissors trophy shown below. I find that Tinkercad is one of the easiest programs to use when combining multiple models together, manipulating scale, and adding vector images. In my classes, I teach Tinkercad to my 6th and 7th grade students and Onshape to my 8th grade students.įor designing trophies, Tinkercad is my program of choice.
There are tons of great Computer Aided Design (CAD) programs out there that can be used to design an awesome trophy. The PLA is not quite as clear as T-Glase, but it is far cheaper and prints and bonds with greater ease. I used to print translucent sections with T-Glase filament, though I recently switched to Natural PLA. I find that PETg has a more glossy shine than most PLA brands and contrasts well with the metallic silk filament.Īs an added feature to some of my trophies, I add LED lights.
For this, I typically use eSun PETg filament. I often contrast the metallic parts of the trophy with a shiny black base. I am endlessly impressed with the finish of this filament, it blends the layers nicely and really does have an awesome metallic shine. It costs about $22 per roll, and is offered in 1.75mm and 3mm diameters. They offer it in Gold, Antique Gold, Silver, and Bronze. Here's the filament I prefer for the best appearance with minimal to no finishing work required.įor the metal-like parts of the trophy, I like CC3D Metallic Silk PLA Filament. No matter what, it will still be a cheap plastic trophy, but so are the ones you buy at the dollar store. I hope you enjoy!Ĭhoosing the right filament is one of the most crucial components of a 3D printed trophy. Now, I thought it's about time for me to pass on the tips, tricks, and methods I've learned.
Over the years I've made some good trophies, and some bad ones. Because of this, I can make a trophy within a couple of hours for whatever the reason may be. However, as mentioned above, getting a trophy made quickly can be difficult or expensive and a piece of paper never has the same effect.įortunately, I am a technology, engineering, and design teacher who has access to an army of 3D printers in our maker space.
One of the best ways to do this is to surprise them with a totally awesome trophy that recognizes what they achieved. But no one likes a paper certificate, and ordering trophies can be pricey, boring, and takes time.Īs a teacher, we constantly look to recognize student achievement and find ways to continue to motivate our students to do the best they can and participate. Everyone should recognize these things by letting someone know that you're a big fan of what they achieved. Recognizing hard work, accomplishing great challenges, or acknowledging immense skill and commitment is important and really goes a long way. Everyone loves a trophy, and at some point or another, everyone deserves a one too.
